Uses:
- Ceramic products
- GVT/PGVT Tiles
- Refactory
- Tyre's
- Glass
- Insulators
Sub-Product Specifications
| CHEMICAL PROPERTIES XRF VERIFIED | ||
|---|---|---|
| SiO2 | % | 49.5 |
| Al2O3 | % | 31.0 |
| Fe2O3 | % | 2.57 |
| Ti2O3 | % | 1.51 |
| CaO | % | 0.23 |
| MgO | % | 0.22 |
| K2O | % | 0.57 |
| Na2O | % | 0.11 |
| LOi | % | 12.7 |
| Total | 98.41 | |
| PHYSICAL PROPERTIES | ||
|---|---|---|
| MBI | mg g-1 | 38.6 |
| Sulphate | ppm | 665 |
| pH | - | 7.3 |
| Conductivity | uS | 1,792 |
| Soluble Salt | ppm | 1,260 |
| MoR(Fired) | Kg cm-2 | 328.3 |
| MoR(Dry) | - | 26.8 |
| WABS | % | 2.37 |
| L* | 55-60 | |
| Colour | a* | 4.26 |
| b* | 11.09 | |
| Shrinkage | % | 12.58 |
| Partical Size Distribution by SediGraph | Sleve Residue-wet Retention | ||||
|---|---|---|---|---|---|
| < 7um | % | 96.6 | > 125um | % | 2.04 |
| < 5um | % | 95.9 | > 75um | % | 1.16 |
| < 2um | % | 89.3 | > 45 um | % | 0.56 |
| < 1um | % | 82.1 | Cumulative>45 | % | 3.76 |
Complete Technical Dossier
Download the full spectral analysis, safety data sheets, and industrial application guides for DN-2.
