Uses:
- Ceramic products
- Tiles
- Crockery Items
- Table Ware
- Tyre's
- Glass
- Insulators
Sub-Product Specifications
| CHEMICAL PROPERTIES XRF VERIFIED | ||
|---|---|---|
| SiO2 | % | 50.2 |
| Al2O3 | % | 31.4 |
| Fe2O3 | % | 1.26 |
| Ti2O3 | % | 1.53 |
| CaO | % | 0.21 |
| MgO | % | 0.29 |
| K2O | % | 0.52 |
| Na2O | % | 0.10 |
| LOi | % | 13.0 |
| Total | 98.6 | |
| PHYSICAL PROPERTIES | ||
|---|---|---|
| MBI | mg g-1 | 40.2 |
| Sulphate | ppm | 415.2 |
| pH | - | 7.3 |
| Conductivity | uS | 1,654 |
| Soluble Salt | ppm | 1,200 |
| MoR(extruded) | Kg cm-2 | - |
| MoR(Dry) | - | 35.0 |
| WABS | % | 3.38 |
| L* | 75.2 | |
| Colour | a* | 1.04 |
| b* | 13.3 | |
| Shrinkage | % | 11.9 |
| Partical Size Distribution by SediGraph | Sleve Residue-wet Retention | ||||
|---|---|---|---|---|---|
| < 7um | % | 96.4 | > 125um | % | 0.72 |
| < 5um | % | 95.2 | > 75um | % | 0.65 |
| < 2um | % | 88.4 | > 45 um | % | 0.58 |
| < 1um | % | 83.0 | Cumulative>45 | % | 1.95 |
Complete Technical Dossier
Download the full spectral analysis, safety data sheets, and industrial application guides for UBC-2.
